The radio control panels Major BOS 4VD and Major BOS 8VD are now also available as a version for facilitated desk integration. The keypad and the display board are placed above a bent metal plate, the main board is placed inside the cavity below. The metal plate contains fixing holes in order to mount the device underneath a desk.
Order information as well as a more detailed desciption/drawing can be found here.
(Januar 2019)
After more than 12 years, our consoles Major 4a, Major 5a, Major 4a_MOT, Major 5a_MOT, Major 4a_NX and Major 5a_NX will be replaced by its successors Major 4b and Major 5b.
While the most remarkable difference on the outside is the new ethernet connector, the basic user functions will be still available, just as known from Major 4a/5a. Configuration will be simplified by the use of a self-explanatory web interface. The standard version of Major 4b/5b is able to control analogue and DMR radios (currently Motorola MOTOTRBO / Kenwood NEXEDGE).
Delivery of Major 4b/5b is scheduled for January 2019, while the full functionality for DMR radios will be available in February. Availability of the versions for direct VOIP connection is estimated for end of March.
Please find below the order information for the new versions:
FT-Nr. 681500 Major 4b
with handset and gooseneck microphone
for analogue and DMR radios
FT-Nr. 681510 Major 4b / VOIP
with handset and gooseneck microphone
for analogue and DMR radios
incl. option VOIP
for remote control of the radio via IP
FT-Nr. 714500 Major 5b
with gooseneck microphone
for analogue and DMR radios
FT-Nr. 714510 Major 5b / VOIP
with gooseneck microphone
for analogue and DMR radios
incl. option VOIP
for remote control of the radio via IP
FT-Nr. 636510 Option VOIP für Major 4b/5b
remote control of the radio via IP
Please don‘t hesitate to contact us in case further information is needed.
(December 2018)
In cooperation with the Rheinisch-Bergischer Kreis we developped a crossborder solution that enables the communication of a control center that still uses analogous radios with personnel that is equipped with digital (TETRA) radios. Besides the mandatory bidirectional voice transition, a complete end-to-end status transition including acknowledgement is realized for the first time.
We are glad to announce that, after a short trial period, the FunkTronic Crossborder D/A is in live operation now, highlighting our experience in both - digital and analogous - radio control systems. Please find a more detailed description in the respective leaflet. If you are interested in a similar solution, don't hesitate to contact us.
(November 2018)
Sandan CarManager is a 7" touch display, that ideally complements the functionality of our new table-top control panels Major BOS 4VD and Major BOS 8VD. Depending on its configuration the CarManager is able to provide a subset of the following features:
- Alerting of personnel via the TETRA network
- Display of feedback from alerting
- Display of personnel status and GPS position
- Offline map based on Open-Streetmap© (only Germany atm)
- Use of several other maps via internet
- Start one-touch call with predefined ISSIs
- One-touch selection of predefined talkgroups
The Sandan CarManager was confirmed to operate via the PEI multiplexer of the FT638 digital radio box. Hence, it can be used in addition to our Major BOS 4VD/8VD consoles with the same TETRA radio. During introduction of the CarManager the connection of one or two TETRA radios (e.g. 1x talk group + 1x data group) will be possible with the standard version. Please contact us if you are interested in the Sandan CarManager.
(October 2018)
With the Major BOS 4VD another voice-over-IP console with TFT display comes into play. With control elements for only up to 4 radios it is more ideally suited in many environments.
Using our new FT638 as the counterpart on the radio site, the additional informations and functionalities of TETRA radios can be used and displayed directly on the console.
In order to reduce the additional training effort of the users to a minimum level, the well-known user interface of the Major BOS 8a is retained.
The new functions are realized via a self-explanatory menu structure.
The following features are planned:
- display of caller's ISSI
- display of recent conversations including time of the call
- display of current TETRA group and folder
- display of current date and time
- current signal strength (RSSI)
- changing the TETRA group
- changing the mode of operation
- transmit and display status
- display SDS messages
Optionally, the Major BOS 4VD can have 8 connections, from which the dispatcher can freely choose those 4 terminals that fulfill the current mission requirements.
The use of legacy radios via direct PTT/SQL is also possible using the FT636B as the counterpart at the radio site.
Delivery of the Major BOS 4VD starts in July, 2018. － Info / Manual
(May 2018)
With the Major BOS 8VD FunkTronic is developping a new voice-over-IP console with TFT display.
Using our new FT638 as the counterpart on the radio site, the additional informations and functionalities of TETRA radios can be used and displayed directly on the console.
In order to reduce the additional training effort of the users to a minimum level, the well-known user interface of the Major BOS 8a is retained.
The new functions are realized via a self-explanatory menu structure.
The following features are planned:
- display of caller's ISSI
- display of recent conversations including time of the call
- display of current TETRA group and folder
- display of current date and time
- current signal strength (RSSI)
- changing the TETRA group
- changing the mode of operation
- transmit and display status
- display SDS messages
The use of legacy radios via PTT/SQL is also possible using the FT636B as the counterpart at the radio site.
Delivery of the Major BOS 8VD starts in January, 2018. － Manual
(November 2017)
The table-top communication unit TKE-2 is a desktop microphone with a universal connection interface. Furthermore,
it has a loudspeaker integrated in its pedestal and comes with one or two buttons. The main difference to our other
desktop microphone is the possibility to connect several TKE-2 in parallel, because the microphone line is only connected
to the respective output, when PTT is pressed. － Manual
(November 2017)
The digital radio box FT638 is a voice-over-IP (VoIP) interface for 2 TETRA radios, e.g. Motorola MTM800 FuG (ET) / MTM5000 series and Sepura SRG3900.
In addition to voice transmission, the function set that can be realised via the Peripheral Equipment Interface (PEI) is also placed at the disposal
of the VoIP participant. Examples are: display of caller ISSI, group selection, selection of operation mode (DMO/TMO...), transmission of status, SDS functions, time display of network server time.
An integrated PEI AT multiplexer enables the possibility to add an additional PEI AT participant per radio. Hence, the FT638 can be integrated
into already existing systems, too. In addition to the standard version, an IN/OUT-version of FT638 is available. Here, up to 3 PEI AT participants
can be connected to a single MRT, one of them also including voice connection.
Possible VoIP counterparts are Major BOS 1V, 4V and 8V, as well as Major BOS 8VD (ETA: Jan/2018) and Commander 6D (with rest ETH, under development). － Manual
(September 2017)
The desktop microphone with universal interface is a unit supporting several applications (PA systems, radios, conference rooms, for example).
It features a loudspeaker and provides one or two keys. － Manual
(January 2017)
The interface Major BOSx Sepura SRG3900 can now be ordered with the option "soft key functions" (article no. 903060.F). In standard configuration, it enables the use of the
soft key functions 4+5 via the Major's call buttons. － Manual-DE
(July 2016)
In the past months FunkTronic GmbH contracted alliaces with both major manufacturers of TETRABOS two way radios. As a partner of Motorola respectively
Sepura we can integrate new functionality at an early stage and achieve addtional benefit for our customers.
(April 2016)
Future announcements on the "News" page will also be sent as a newsletter email. It will provide information about new products, new and updated manuals and fürther news.
To receive this newsletter you need to register via the link Subscribe to Newsletter.
Unregister at the same place, if you do not like to receive the newsletter any longer.
(February 2016)
The project FT638 TETRA Universal Interface is currently under development at FunkTronic GmbH. It will provide several options to connect control heads and accessories to TETRA two way radios.
It will be available in the black box housing as well as module for 19" racks.
Supported devices:
- Handheld control head Commander 6 IP with network interface
- VoIP desktop control heads Major BOS V1, V4, V8
- Analog control heads, for example.
- Commander secondary control head
- Commander BOS 2
- Major BOS 1a, 4a, 8a
- PEI accessories, for example status keys, status displays
- Additional devices, for example Navi /GPS Modul, GSM Voice Date Modul (planed)
- Send status
- Receive/display directive
- Direct call
- Group call
- Talker group selection
- Talker group display
- Receive/display SDS
Because the product is still under development the naming, appearance, layout and functionality may change. Because of this the brochure may not reflect the actual state of the project.
(January 2016)
The TETRA interface C5/6FuG8 (for Ascom oder Bosch) is available for Motorola's MTM800 FuG (ET) and Sepura's SRG3900 with firmware-Version 1.02.
Details can be found in the Manual (German) and/or brochure
(Sepura or Motorola).
The TETRA interface allows the handheld control head Commander 6 BOS (with restrictions also the Commander 5 BOS, option TETRA required for both) to connect to a analog radio FuG8b-1
and also to a Motorola MTM800 FuG (ET) or a Sepura SRG3900. The digital or analog radios can be used alternatively.
The previous functionality of the analog mode is still in complete working order.
(January 2016)
For the FunkTronic devices FT636B IP Interface und Major BOS V software updates are available.
The updates will be provided on request.
FT636B:
- Second ethernet interface with eight addtitional connections
- Download and backup of the configuration to a file
Major BOS V:
- Download and backup of the configuration to a file
(January 2016)
The programmer PROG C6 to update the firmware of the Commander 6 BOS/FMS via PC or Laptop. Additonally the configuration of the Commander 6 can be read and stored to a file.
This file can be used for restore of the programming of a Commander 6 or can be loaded to any other Commander 6.
The box has a RJ45 plug and a NATO plug to connect to the Commander 6 (via support O). － Manual-DE
(July 2015)
The new Commander 6 is available, therefore the Commander 5 has been taken out of production. The Commander 6 BOS/FMS is available in the same versions and to the same conditions
as the old Commander 5 BOS/FMS.
(January 2015)
The distribution frame for RJ-45 is used for parallel connection of several Major BOS to one radio circuit.
It is available in 2 different versions (7-fold or 2x3-fold) － Manual-DE
(June 2014)
The radio control panels Major BOS 2b, Major BOS 4a and Major BOS 8a are now also available as a version for facilitated desk integration.
The keypad and the display board are placed above a metal bar, which contains fixing holes in order to mount the device from below to a table plate. － Manual-DE
(June 2014)
The Commander 6 FMS and Commander 6 BOS received the BOS certification through the accredited laboratory of the Landesfeuerwehrschule Baden-Wurtemberg.
The Commander is compatible with the available rests (O, E, ED und K) and with the radio interfaces C5FuG8/9.
The commander 6 supports every functionality the Commander 5 does. In addition it uses a coulor display for better representation and menu guided configuration.
－ Manual-DE C6 FMS
－ Manual-DE C6 BOS
(May 2014)
The new FT636B IP Interface is now available.
In addition to the functionality of its ancestor (FT636) the following features have been (or will be) implemented:
- a secondary ethernet interface to realize redundancy (planned)
- a second serial interface to allow for remote control of two digital radios
- additional LEDs for status display
- support of up to 8 (planned: 16) remote radios / control sets in different locations
- support of up to 16 switchable in-/outputs (planned)
- support of tone signalling (single tones / tone sequences)
- improved web interface
- programming functions instead of registers
- enhanced monitoring of connection status and error messages
- improved configuration of level settings
- accelerated establishing of connections, further minimization of reconnects
(February 2014)
